Nissan 360° Around View Monitor (AVM) Calibration Boards

Our Nissan AVM Calibration Board Set is designed to accurately calibrate the vehicle’s 360° Around View Monitoring (AVM) system. The high-contrast calibration patterns and precision-manufactured dimensional standards allow the AVM system to correctly identify and calibrate the position of each camera, ensuring the correct surround-view image is displayed to the driver. This provides a straightforward, accurate and consistent calibration process.

Compatible Manufacturer

These AVM Calibration Boards are compatible with the following manufacturer:

Nissan

Precision Manufactured for Accurate AVM Calibration

Each calibration board is manufactured from premium lightweight Dibond®, providing exceptional rigidity, durability and dimensional stability to support accurate and repeatable calibration procedures.

The high-contrast calibration graphics are produced using specialised UV solvent printing technology with advanced automated manufacturing processes, ensuring exceptional print accuracy and consistency across every board.

The matte non-glare finish helps minimise unwanted reflections from workshop lighting, allowing the AVM system to accurately recognise the calibration patterns and supporting reliable calibration results.

The scratch-resistant printed surface is designed to withstand repeated workshop use while maintaining the precision required for professional ADAS calibration.

Premium Dibond® Calibration Boards

Designed for Professional Workshop Use

Developed for accuracy, durability and long-term workshop performance, these premium Dibond® calibration boards provide a dependable solution for professional AVM calibration procedures.

The lightweight aluminium composite construction offers excellent strength while remaining easy for technicians to transport, position and store.

Unlike flexible calibration mats, the rigid board design helps maintain perfectly flat calibration targets, supporting consistent positioning throughout the calibration process.

Each board features high-quality UV solvent printed graphics, delivering outstanding contrast, exceptional durability and long-lasting performance, even with frequent workshop use.

Key Benefits

• Premium lightweight Dibond® construction for strength and durability
• Rigid calibration boards help maintain accurate positioning
• UV solvent printed for exceptional pattern clarity and long-lasting performance
• Scratch-resistant printed surface
• Non-glare matte finish helps reduce LED light reflection
• Lightweight design for easy handling and transportation
• Designed for accurate and repeatable 360° camera calibration
• Compatible with Nissan AVM calibration procedures

Package Includes

• 7 Calibration Boards
